Build an AI Appointment Booking System with Vapi and Calendly: The Complete Step-by-Step Guide

This is the execution guide for building the AI Appointment Booking Automation business we outlined in our opportunity deep‑dive. Follow the steps below and you will have a fully‑functional, voice‑powered scheduling system that can be sold to medical practices, law firms, or any service‑based business that needs to reduce no‑shows and manual booking overhead.

Ready to understand the full business opportunity? Read our opportunity deep‑dive.

Prerequisites

Note: All costs are the lowest paid tiers that include the APIs we will use. You can start on free tiers and upgrade after you validate the business model. The total monthly investment is less than a single client pays you, so the unit economics work from day one.

Step 1: Setup Accounts and API Keys

Goal: Create all necessary accounts, generate API keys, and store them securely in Replit ’s secrets manager.

1.1 Create a Vapi Account

1. Navigate to https://app.vapi.io.
2. Click Sign Up and enter your email and password, then click Create Account.
3. Verify your email address through the confirmation link sent to your inbox.
4. Log in to the Vapi dashboard.
5. In the dashboard, click Manage API Keys and then Create Key.
6. Name the key PROD_VAPI_KEY, set the scope to Read & Write, and click Create.
7. Copy the key to your clipboard immediately — Vapi will not display it again after you navigate away from the page.

Check‑in: Do you see “Manage API Keys” under the Settings menu? If not, ensure you are in the Admin view. Log out and log back in if necessary.

1.2 Create a Calendly Account

1. Go to https://calendly.com and sign up with your email address.
2. Complete the onboarding wizard: set your timezone, default meeting duration, and available hours.
3. In the Integrations tab, click API & Webhooks.
4. Click Generate New API Key and name it CAL_API_KEY.
5. Copy the key to your clipboard.
6. While you are in the API settings, copy your Organization URI and User URI — you will need both for programmatic scheduling.

Check‑in: Do you see your API key listed under “API Keys” with a 32‑character string? If you see “API Key expired”, click Regenerate and copy the new key.

1.3 Create a Make.com Account

1. Visit https://www.make.com and sign up with your email and password.
2. In the dashboard, click Create new scenario.
3. Choose Webhook as your first module and set it to Custom webhook.
4. Copy the Webhook URL — it looks like https://hook.integromat.com/xxxxxx. You will paste this into Vapi later.
5. Name the scenario “Vapi Booking Webhook” and save it.

Check‑in: Do you see a “Webhook” module with a URL that starts with https://hook.integromat.com/? If yes, proceed. If no, make sure you selected the HTTP > Webhooks module and that it is set to “Custom webhook”.

1.4 Store API Keys in Replit Secrets

1. Go to Replit.com, click New Repl, and select the Python template.

2. Name the repl vapi-calendly-booker.

3. In the left sidebar, click the Secrets (Environment Variables) icon (the lock symbol).

4. Add the following secrets one at a time:

   Key	Value
   VAPI_KEY	Your Vapi API key
   CALENDLY_KEY	Your Calendly API key
   CALENDLY_USER_URI	Your Calendly User URI
   MAKESHOP_URL	Your Make.com webhook URL
   ELEVENLABS_KEY	ElevenLabs API key (optional)
   KLAVIYO_API_KEY	Klaviyo API key (optional)

5. Check‑in: Do you see a green checkmark next to each secret? If not, delete the entry and re‑enter the key name and value carefully — typos in secret names are the number one cause of “key not found” errors at runtime.

1.5 Verify Connectivity

Open the Replit Shell and run:

curl -I https://api.vapi.io

You should receive HTTP/2 200. If you see 401 Unauthorized, your VAPI_KEY is incorrect. Verify it in the Vapi dashboard and update the Replit secret. Test Calendly connectivity with:

curl -H "Authorization: Bearer $CALENDLY_KEY" https://api.calendly.com/users/me

You should see a JSON response with your user profile. If you get a 401, regenerate the Calendly API key.

Step 2: Build the Vapi Voice Agent

2.1 Configure the Voice Agent in Vapi Dashboard

1. In the Vapi dashboard, click Create Assistant.
2. Set the assistant name to BookingAgent.
3. Under Voice, select a voice from the ElevenLabs library. Choose a voice that matches your target vertical — a warm, professional female voice works well for dental and medical practices; a confident, direct male voice suits legal and financial services.
4. Under Model, select gpt-4o-mini for cost efficiency. You can upgrade to gpt-4o later if the client needs more nuanced conversation handling.
5. Under System Prompt, paste the following template and customize it for your client:

You are a professional appointment booking agent for [BUSINESS NAME], a [VERTICAL] practice in [CITY]. Your job is to:

1. Greet the caller warmly and ask how you can help them today.
2. Determine what type of appointment they need (e.g., cleaning, consultation, follow-up, emergency).
3. Check available time slots using the Calendly integration.
4. Offer the next 3 available slots and let the caller choose.
5. Confirm the booking by repeating the date, time, and appointment type.
6. Ask if they would like an email or SMS confirmation.
7. Thank them and end the call professionally.

Rules:
- Never give medical, legal, or financial advice.
- If the caller asks a question you cannot answer, say "Let me connect you with a team member who can help with that."
- Always confirm the booking details before ending the call.
- Speak at a natural pace — not too fast, not too slow.
- Use the business's preferred terminology (e.g., "visit" not "appointment" for dental practices).

6. Under Functions, add a new function called check_availability with the following schema:

{
  "name": "check_availability",
  "description": "Check available appointment slots in Calendly",
  "parameters": {
    "type": "object",
    "properties": {
      "event_type": {
        "type": "string",
        "description": "Type of appointment (cleaning, consultation, follow-up)"
      },
      "date_range_start": {
        "type": "string",
        "description": "Start date in YYYY-MM-DD format"
      },
      "date_range_end": {
        "type": "string",
        "description": "End date in YYYY-MM-DD format"
      }
    },
    "required": ["event_type", "date_range_start", "date_range_end"]
  }
}

7. Add a second function called book_appointment:

{
  "name": "book_appointment",
  "description": "Book an appointment in Calendly",
  "parameters": {
    "type": "object",
    "properties": {
      "event_type": { "type": "string" },
      "start_time": { "type": "string", "description": "ISO 8601 datetime" },
      "caller_name": { "type": "string" },
      "caller_email": { "type": "string" },
      "caller_phone": { "type": "string" }
    },
    "required": ["event_type", "start_time", "caller_name", "caller_email"]
  }
}

8. Under Server URL, enter your Make webhook URL. Vapi will POST function call payloads to this URL whenever the AI agent needs to check availability or book an appointment.
9. Click Save and then Test to verify the agent responds correctly to a simulated call.

2.2 Test the Voice Agent

Click Call in the Vapi dashboard to place a test call to your own phone number. Walk through the entire booking flow:

• Say “I’d like to schedule a cleaning.”
• When the agent offers time slots, choose one.
• Confirm the booking.
• Check that the function call payload arrived in your Make.com scenario.

If the agent does not call the functions, check that the Server URL is correct and that your Make.com webhook is active (it must receive at least one test payload before it starts listening for real data).

Step 3: Build the Make.com Automation Scenarios

3.1 Scenario 1: Check Availability

This scenario receives a check_availability function call from Vapi, queries the Calendly API, and returns available slots.

1. In Make.com, create a new scenario called “Check Availability.”
2. Add a Webhook module as the trigger. Use the same webhook URL you configured in Vapi.
3. Add a HTTP module configured as follows:
   • Method: GET
   • URL: https://api.calendly.com/user_availability_schedules
   • Headers: Authorization: Bearer {{CALENDLY_KEY}}
4. Add a JSON Parser module to extract the available time slots from the Calendly response.
5. Add a Webhook Response module that returns the available slots to Vapi in the format it expects:

{
  "result": [
    {"start_time": "2026-05-05T09:00:00Z", "end_time": "2026-05-05T09:30:00Z"},
    {"start_time": "2026-05-05T10:00:00Z", "end_time": "2026-05-05T10:30:00Z"},
    {"start_time": "2026-05-05T14:00:00Z", "end_time": "2026-05-05T14:30:00Z"}
  ]
}

6. Save and activate the scenario.

3.2 Scenario 2: Book Appointment

This scenario receives a book_appointment function call, creates the booking in Calendly, sends a confirmation email, and logs the booking in the CRM.

1. Create a new scenario called “Book Appointment.”
2. Add a Webhook module as the trigger.
3. Add an HTTP module to create the Calendly booking:
   • Method: POST
   • URL: https://api.calendly.com/scheduled_events
   • Headers: Authorization: Bearer {{CALENDLY_KEY}}, Content-Type: application/json
   • Body:

   {
     "event_type": "{{1.event_type}}",
     "start_time": "{{1.start_time}}",
     "invitee": {
       "name": "{{1.caller_name}}",
       "email": "{{1.caller_email}}",
       "phone": "{{1.caller_phone}}"
     }
   }


4. Add an Email module to send a confirmation to the caller:
   • To: {{1.caller_email}}
   • Subject: Your Appointment is Confirmed — [BUSINESS NAME]
   • Body: Include the appointment date, time, type, and a link to reschedule or cancel.
5. Add an HTTP module to log the booking in ActiveCampaign or Klaviyo (optional but highly recommended for churn prevention).
6. Add a Webhook Response module to confirm the booking back to Vapi:

{
  "result": "Booking confirmed for {{1.caller_name}} on {{1.start_time}}. Confirmation email sent."
}

7. Save and activate the scenario.

3.3 Scenario 3: Appointment Reminders

This scenario runs on a schedule and sends automated reminders to reduce no‑shows.

1. Create a new scenario called “Appointment Reminders.”
2. Add a Scheduler trigger set to run every hour.
3. Add an HTTP module to fetch upcoming Calendly events within the next 24 hours.
4. Add an Iterator module to loop through each event.
5. Add a Filter module that passes only events where a reminder has not yet been sent (track this with a custom field in your CRM).
6. Add an SMS module (via Twilio or ClickSend) to send a reminder: “Hi {{name}}, this is a reminder that you have an appointment at {{business_name}} tomorrow at {{time}}. Reply C to confirm or R to reschedule.”
7. Add an HTTP module to update the CRM record marking the reminder as sent.
8. Save and activate the scenario.

Step 4: Build the Replit Webhook Handler

While Make.com handles most of the automation logic visually, you need a lightweight server to handle edge cases, custom transformations, and fallback logic. This is your Replit app.

4.1 Project Structure

/vapi-calendly-booker
├── app.py              # Flask webhook server
├── calendly.py         # Calendly API wrapper
├── requirements.txt    # Python dependencies
└── .env               # Environment variables (for local dev)

4.2 Install Dependencies

Open the Replit Shell and run:

pip install flask requests python-dotenv
pip freeze > requirements.txt

4.3 The Webhook Server (app.py)

import os
import json
import requests
from flask import Flask, request, jsonify

app = Flask(__name__)

VAPI_KEY = os.getenv("VAPI_KEY")
CALENDLY_KEY = os.getenv("CALENDLY_KEY")
CALENDLY_USER_URI = os.getenv("CALENDLY_USER_URI")

@app.route("/vapi/webhook", methods=["POST"])
def vapi_webhook():
    """Handle function calls from Vapi voice agent."""
    payload = request.json
    function_name = payload.get("function", {}).get("name")
    arguments = payload.get("function", {}).get("arguments", {})

    if function_name == "check_availability":
        return handle_check_availability(arguments)
    elif function_name == "book_appointment":
        return handle_book_appointment(arguments)
    else:
        return jsonify({"error": f"Unknown function: {function_name}"}), 400

def handle_check_availability(args):
    """Query Calendly for available slots."""
    event_type = args.get("event_type")
    start_date = args.get("date_range_start")
    end_date = args.get("date_range_end")

    headers = {"Authorization": f"Bearer {CALENDLY_KEY}"}
    params = {
        "user": CALENDLY_USER_URI,
        "start_time": f"{start_date}T00:00:00Z",
        "end_time": f"{end_date}T23:59:59Z",
    }

    response = requests.get(
        "https://api.calendly.com/user_availability_schedules",
        headers=headers,
        params=params,
    )

    if response.status_code != 200:
        return jsonify({"result": "I'm sorry, I couldn't check availability right now. Please try again."})

    slots = parse_available_slots(response.json())
    return jsonify({"result": format_slots_for_voice(slots)})

def handle_book_appointment(args):
    """Create a booking in Calendly."""
    headers = {
        "Authorization": f"Bearer {CALENDLY_KEY}",
        "Content-Type": "application/json",
    }
    booking_data = {
        "event_type": args.get("event_type"),
        "start_time": args.get("start_time"),
        "invitee": {
            "name": args.get("caller_name"),
            "email": args.get("caller_email"),
            "phone": args.get("caller_phone", ""),
        },
    }

    response = requests.post(
        "https://api.calendly.com/scheduled_events",
        headers=headers,
        json=booking_data,
    )

    if response.status_code in (200, 201):
        return jsonify({"result": f"Booking confirmed for {args.get('caller_name')} on {args.get('start_time')}. A confirmation email has been sent."})
    else:
        return jsonify({"result": "I'm sorry, I couldn't complete the booking. Please try again or call the office directly."})

def parse_available_slots(data):
    """Extract and format available time slots from Calendly response."""
    # Implementation depends on Calendly API version
    # This is a simplified example
    slots = []
    for day in data.get("days", []):
        for slot in day.get("slots", []):
            slots.append({
                "start": slot.get("start_time"),
                "end": slot.get("end_time"),
            })
    return slots[:3]  # Return next 3 available slots

def format_slots_for_voice(slots):
    """Format slots into natural language for the voice agent."""
    if not slots:
        return "I'm sorry, there are no available slots in that time range. Would you like to check a different week?"

    messages = []
    for i, slot in enumerate(slots, 1):
        start = slot["start"]
        # Convert to natural language
        day_name = parse_day_name(start)
        time_str = parse_time(start)
        messages.append(f"Option {i}: {day_name} at {time_str}")

    return "I found the following available times: " + ". ".join(messages) + ". Which works best for you?"

def parse_day_name(iso_datetime):
    """Convert ISO datetime to day name."""
    from datetime import datetime
    dt = datetime.fromisoformat(iso_datetime.replace("Z", "+00:00"))
    return dt.strftime("%A, %B %d")

def parse_time(iso_datetime):
    """Convert ISO datetime to readable time."""
    from datetime import datetime
    dt = datetime.fromisoformat(iso_datetime.replace("Z", "+00:00"))
    return dt.strftime("%I:%M %p")

if __name__ == "__main__":
    app.run(host="0.0.0.0", port=8080)

4.4 Deploy and Test

1. Click Run in Replit to start the Flask server.
2. Copy the Replit URL (e.g., https://vapi-calendly-booker.username.repl.co).
3. Update the Vapi assistant’s Server URL to point to https://your-repl.repl.co/vapi/webhook.
4. Place another test call through the Vapi dashboard and verify that the agent can check availability and book appointments end‑to‑end.

Step 5: Deploy to Production on Hostinger

When you are ready to move off Replit’s shared infrastructure, deploy to a Hostinger VPS for reliability and performance.

5.1 Server Setup

1. Purchase a Hostinger VPS plan (the $9.99/month plan with 4 GB RAM is sufficient for handling 500+ concurrent webhook requests).
2. SSH into your server: ssh root@your-server-ip.
3. Install Python 3, pip, and nginx:

sudo apt update && sudo apt upgrade -y
sudo apt install python3 python3-pip python3-venv nginx -y

4. Clone your Replit project:

git clone https://github.com/your-username/vapi-calendly-booker.git
cd vapi-calendly-booker

5. Create a virtual environment and install dependencies:

python3 -m venv venv
source venv/bin/activate
pip install -r requirements.txt gunicorn

6. Set environment variables by creating a .env file with your production API keys.

5.2 Configure Gunicorn as a System Service

Create a systemd service file at /etc/systemd/system/vapi-booker.service:

[Unit]
Description=Vapi Calendly Booking Agent
After=network.target

[Service]
User=www-data
WorkingDirectory=/root/vapi-calendly-booker
Environment="PATH=/root/vapi-calendly-booker/venv/bin"
ExecStart=/root/vapi-calendly-booker/venv/bin/gunicorn -w 4 -b 0.0.0.0:8080 app:app
Restart=always

[Install]
WantedBy=multi-user.target

Enable and start the service:

sudo systemctl enable vapi-booker
sudo systemctl start vapi-booker

5.3 Configure Nginx Reverse Proxy

Create an nginx configuration at /etc/nginx/sites-available/vapi-booker:

server {
    listen 80;
    server_name booking.yourdomain.com;

    location / {
        proxy_pass http://127.0.0.1:8080;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

Enable the site and restart nginx:

sudo ln -s /etc/nginx/sites-available/vapi-booker /etc/nginx/sites-enabled/
sudo nginx -t
sudo systemctl restart nginx

Add SSL with Let’s Encrypt:

sudo apt install certbot python3-certbot-nginx -y
sudo certbot --nginx -d booking.yourdomain.com

Update the Vapi assistant’s Server URL to https://booking.yourdomain.com/vapi/webhook.

Step 6: Monitoring and Maintenance

6.1 Set Up Health Checks

Add a health check endpoint to your Flask app:

@app.route("/health", methods=["GET"])
def health():
    return jsonify({"status": "healthy", "timestamp": datetime.utcnow().isoformat()})

Use a free monitoring service like UptimeRobot to ping this endpoint every five minutes. If it goes down, you will get an email alert before your clients notice.

6.2 Log All Booking Events

Create a simple logging middleware that records every webhook payload:

import logging

logging.basicConfig(
    filename="bookings.log",
    level=logging.INFO,
    format="%(asctime)s - %(name)s - %(levelname)s - %(message)s",
)

@app.before_request
def log_request():
    if request.path.startswith("/vapi"):
        logging.info(f"Webhook received: {request.json}")

These logs are invaluable for debugging integration issues and providing audit trails to clients who ask “Did the AI book that appointment correctly?”

6.3 Weekly Reporting Dashboard

Build a simple reporting page that displays:

• Total bookings this week vs. last week
• Booking conversion rate (calls received vs. appointments booked)
• No‑show rate for AI‑booked appointments vs. manually booked appointments
• Average time from call to confirmed booking
• Most common appointment types

You can build this with a simple Flask route that queries your booking log and renders an HTML template, or connect the data to a Google Sheet that updates automatically via Make.com.

Step 7: Onboarding Your First Client

7.1 Pre‑Onboarding Checklist

Before onboarding a new client, complete the following:

• Client has signed the service agreement and provided payment details
• Client has shared their Calendly login or API key
• Client has provided their business name, address, and preferred terminology
• Client has confirmed their available hours and appointment types
• Client has designated a point of contact for technical questions
• You have created a Vapi assistant with the client’s custom system prompt
• You have configured the Make.com scenarios for the client’s specific workflow
• You have tested the end‑to‑end flow with the client’s real Calendly account

7.2 Phone Number Provisioning

Purchase a dedicated phone number for each client through Vapi or a provider like Twilio. The number should be local to the client’s area code — callers are 40% more likely to answer a local number. Configure the number to forward to the Vapi assistant during business hours and to voicemail after hours.

7.3 Go‑Live Process

1. Forward the client’s existing phone line to the new AI number (or set up a parallel ring so both the human receptionist and the AI receive calls simultaneously during the transition period).
2. Monitor the first 48 hours of calls closely. Be available to intervene manually if the AI mishandles a call.
3. After 48 hours, review call transcripts with the client and make adjustments to the system prompt, available appointment types, or call routing logic.
4. After two weeks, generate a performance report comparing the AI‑assisted booking rate to the client’s historical baseline.

Troubleshooting Common Issues

Recommended Tools

These are the tools we recommend for building and scaling AI automation businesses:

• Vapi — AI voice agent platform — build and deploy voice AI
• Make.com — Visual automation platform — connect any app without code
• ElevenLabs — AI voice synthesis — human‑quality voiceovers and agents
• Semrush — SEO and content marketing — outrank your competitors
• Replit — Cloud IDE — build and deploy without infrastructure
